Introduce
for copper, aluminum, gold, silver, nickel, platinum, zinc, tin, tantalum-niobium and other non-ferrous metals and some of their alloy wire cold welding.
Technical parameter
|
Scope of wires: |
Cu:φ3.00mm~φ9.50mm ALφ3.00mm~φ13.50mm AI Alloy:φ3.00mm~φ9.00mm |
|
Frame type: |
Precise casting |
|
Electrical power: |
22KW |
|
Oil Temperature: |
≤65° |
|
Oil Return pressure |
0.5~0.8Mpa |
|
Rated voltage: |
380V/50Hz |
|
Work pressure: |
3.8~4.0Mpa |
|
Dimensions: |
(LxWxH)1300×730×1200mm |
|
Weight |
650kg |
SAM always focus on set the whole suppily chain of cable and wire field. If you want to know more machine click on the icon below and know more.
Sam Mould Company started in the wire and cable equipment manufacturing industry in 1995, and is familiar with the production and operation of wire and cable equipment. With the continuous development of the company's business, Sam decided to focus on the production of molds....[ read more ]
